For products in stock, we ship immediately. Otherwise, production typically takes 7-10 working days.
VDE H05S-K
Technical Parameter：
- Rated voltage: 300V/500V
- Rated Temperature: 180℃
- Standard: VDE 0282-3
Product Description
Silicone wire is a type of wire that uses silicone as its insulation material. Its main feature is its excellent high temperature resistance, able to maintain stable performance in temperature ranges from -50°C to +200°C or even higher. Additionally, silicone wire possesses good resistance to chemical corrosion, able to withstand the corrosion of acids, alkalis, solvents, and other chemical substances. Its flexible and abrasion-resistant characteristics make it suitable for complex wiring environments. Silicone wire is widely used in household appliances, automotive electronics, medical devices, industrial equipment, aerospace, construction, drones, and other fields.
| 導體(Conductor) | 絕緣體 Insulation | 導體電阻 Max.Cond Resistance (Ω/KM) | 包裝 Unit Length (M)/(Ft) | |||
| 線規 Size (AWG) | 線數/線徑 Construction (No./mm) | 直徑 Diameter (mm) | 絕緣厚度 Nominal Thickness (mm) | 完成外徑 Diameter (mm) | ||
| 0.5 | 20/0.18 | 0.75 | 0.8 | 2.52 | 40.1 | 305/1000 |
| 0.75 | 30/0.18 | 1.13 | 0.8 | 2.73 | 26.7 | |
| 1 | 40/0.18 | 1.3 | 0.8 | 2.91 | 20 | |
| 1.25 | 50/0.18 | 1.5 | 0.8 | 3.06 | 14.35 | |
| 1.5 | 30/0.25 | 1.6 | 0.9 | 3.4 | 13.7 | |
| 2 | 41/0.254 | 1.85 | 0.9 | 3.67 | 8.78 | |
| 2.5 | 50/0.25 | 2.06 | 1 | 4.08 | 7.16 | |
FAQ
How soon can I expect delivery?
What is your MOQ?
MOQs vary by product. For wires and cables ranging from 28AWG to 18AWG, it's 6100 meters. For 16AWG to 12AWG, it's 3050 meters. Beyond 10AWG, the MOQ is 1000 meters.
What are your available transportation methods?
We offer transportation by sea, land, and air.
What payment methods do you accept?
We accept various payment methods. Our recommendations are 100% T/T or PayPal before production, or a 70% T/T deposit with the remaining 30% balance due before shipment.
How do you handle quality issues?
In case of any quality concerns, we will promptly resend fully-qualified products to you.
