产品描述
Silicone wire is a type of wire that uses silicone as its insulation material. Its main feature is its excellent high temperature resistance, able to maintain stable performance in temperature ranges from -50°C to +200°C or even higher. Additionally, silicone wire possesses good resistance to chemical corrosion, able to withstand the corrosion of acids, alkalis, solvents, and other chemical substances. Its flexible and abrasion-resistant characteristics make it suitable for complex wiring environments. Silicone wire is widely used in household appliances, automotive electronics, medical devices, industrial equipment, aerospace, construction, drones, and other fields.
| 導體(Conductor) | 絕緣體 Insulation | 導體電阻 Max.Cond Resistance (Ω/KM) | 包裝 Unit Length (M)/(Ft) | |||
| 線規 Size (AWG) | 線數/線徑 Construction (No./mm) | 直徑 Diameter (mm) | 絕緣厚度 Nominal Thickness (mm) | 完成外徑 Diameter (mm) | ||
| 28 | 7/0.127 | 0.38 | 1.15 | 2.68 | 227 | 610/2000 |
| 26 | 7/0.16 | 0.48 | 2.78 | 143 | ||
| 24 | 7/0.20 | 0.61 | 2.91 | 89.3 | ||
| 22 | 7/0.254 | 0.77 | 3.07 | 56.4 | 305/1000 | |
| 20 | 7/0.30 | 0.92 | 3.22 | 35.2 | ||
| 18 | 7/0.39 | 1.19 | 3.49 | 22.2 | ||
| 16 | 7/0.49 | 1.49 | 3.79 | 14 | ||
| 14 | 41/0.254 | 1.87 | 4.17 | 8.78 | 153/500 | |
| 12 | 65/0.254 | 2.36 | 4.66 | 5.53 | ||
| 10 | 19/0.61 | 3 | 5.3 | 3.48 | ||
常见问题
交期是多久？
怎么发货？
现货商品当天16点前下单，当天发货；备货商品七天内安排发货。默认发优速快递，如需其他快递公司发货请提前备注。
如何处理质量问题？
以下情况不支持退换货服务：
1、拍散线，在已剪情况下，不退换；未剪的散线可退换，需联系客服。2、线缆包装已拆封，如无因质量等问题不支持退换货，请悉知。3、商品有污损（如线缆包装表面有油漆、涂料等）4、线缆表面有损伤，影响二次销售的不支持退换货。
如何订货？
请直接联系我们。
